STEMI 305 (Stereo Zoom Microscope from Carl Zeiss)
STEMI 305 (Stereo Zoom Microscope from Carl Zeiss)
STEMI 305 is a Trinocular Stereo Zoom microscope from Cael Zeiss. STEMI 305 provides high quality images, with a field of view of up to 40 mm.
Technical Specification
- High performace optics with brilliant sharp distortion free and high resolution images
- Zoom ration 5:1
- Magnitifation from 8X to 40X
- Engageable click stop Zoom possitions for reproducible measurements
- C Mount Adapter
- C Mount objectives 0.5X
- Reduction lens
- LED reflected (TOP ring light for better shadowless illumination)
- Greenough system
- Manually operable zoom 5:1 (0.8x…4.0x) on both sides
- Fixed zoom click stops 0.8x-1x-2x-3x-4x
- Free working distance 110 mm
- Viewing angle 45° with adjustable interocular distance 55…75 mm
- Eyepieces 10x/23 Br. foc.
- Stand K MAT
- Column 250 mm with drive and handle, lifting range 145 mm
- Stemi mount d=76 mm, load capacity 5 Kg, adjustable friction
- RL control for on/off/dimming
- ESD protection feature: Antistatic surface, grounding socket
- Integrated power unit 12V DC 24W/100…240V AC/50…60Hz
- B/W plastic plate D=84×5 mm
- Dust cover
- Ring Illuminator
